To read oil and coolant temperature on the Jeep I wanted to use automotive parts for the sensors. Most temperature sensors in the automotive world are thermistors. I searched around for some in 1/8″ NPT and found some designed for aftermarket gauges. Only problem was there was no datasheet for them…which is necessary to accurately read the thermistors since they are non linear devices. At under $4 a piece I ordered them anyways.
Fortunately when they arrived they had a part number on them and after some googling I managed to find a temperature chart.
I double checked the values with a multimeter and setting the hot air gun to the temperatures in the chart above and seeing what the resistance was. Everything matched.
To read the thermistors I decided to use the MAX6682 IC. This IC gets rid of power supply noise and thermal self heating of the thermistor.
The only thing I had to calculate was the REXT value. I used the 2031 ohm (20C) for RMAX, 108 ohm (100C) for RMIN, and 388 ohm (60C) for RMID. This came out to a value of 287 ohms. Which the resistor ERA-3AEB2870V by Panasonic works. See page 6 of the datesheet for the formula to calculate REXT.
Then I drew up the schematic and layout for the breakout board.
I added a little header (J3) that will allow me to easily change the REXT value for other thermistors.
Climate controlled seats in your car are probably one of the greatest inventions since sliced bread if you live down in humid hot climates (like Houston!). Since trying them out in my Dad’s Tahoe years ago I have always wanted them in my Jeep but no one really makes after market seats that have them and there are no “kits” like adding heating elements to seats.
This changes now!
I managed to snag a 2015 Ford F-150 seat climate control module unit on ebay for $40. I picked this unit cause it looked compact and looking at the wiring from pictures I found on the internet it looked like I could reasonably make this work.
So how these work is via the peltier effect. The peltier unit has two copper heatsinks attached, one for each side. When voltage is applied to the peltier unit one side gets hot and the other cold. This is transferred to the copper heatsinks where the fan blows creating a stream of lava hot air and arctic frost air.
This is the peltier unit removed from the housing. The blue and yellow wires ended up being the peltier unit and after some testing the green and gray wires seem to be a NTC 200K thermistor. With 12V on the peltier in heating mode the resistance is 54K ohms. With 12V on the peltier in cooling mode it is 240K ohms. Room temperature resistance is around 170K ohms.
The fan is interesting. There are three wires. Red, black, and white. I figured red is power (12V), black is ground, and white is a pulse that I can measure and find the RPM for feedback control similar to the thermistor on the peltier.
Wired up the fan with 12V on red and ground on black. No go. Attached the white wire to 12V and it spun up! Pulling 1.4 Amps. Cool. Then the red wire fell off the wire clip and it was still spinning. 12V on the white wire (still at 1.4A!) and nothing on the red…. Weird.. Why is that? Maybe the red wire was feedback? Looking at the signal on the scope proved that was not the case. Time to open it up!
I took the fan out of the plastic housing. Looks like the PCB is directly on the aluminum or steel backing plate? The blades/cage of the fan is attached with a blind c clip in a bronze bushing on the back of the fan. This was pretty difficult to remove but a sharp pick and screwdriver I managed to remove it.
Yup! The PCB is on an aluminum or steel substrate (need to check which one) instead of the typical FR4 base. All single sided routed.
Red wire is labeled VM, Black is GND, and the White wire is VSP. I manged to get a part number from the large IC labeled IC1 on the upper right. The LB11988 is a brushless motor controller from On Semiconductor. T1 is labeled 065886A and is a DPAK package. I dunno what this part is at this point. Looking at DPAK mosfet parts the pinout makes sense. It also could be a large BJT. I then drew up a schematic.
The VCC pin on the LB11988 powered the internal control circuitry for the IC and VS is the motor power from I can gather. The datasheet is a bit vague here.
If the Red wire is disconnected the White wire provides all the power to the motor. That means that the T1 part either has a blown gate if its a mosfet (mosfets are not supposed to pull significant or any power through the fate) or T1 is a BJT with crazy base junction current.
I removed the T1 part and tested so see if it was a BJT and sure enough I was able to measure the diode effect from base to collector and base to emitter. Looking at DPAK BJTs that are automotive grade shows that some of them can have up to 2A of base current….Checks out I suppose!
With the mysterious of the unit solved it is time to develop a controller for it. I have read that the peltiers used in these units are powered via 16V but I can not confirm. Maybe a 12V -> 16V step up is needed that is rated for 8A. Lots of power need :)
I was able to get the engine stand completed and engine running again.
The old exhaust system was pretty much cracked and fell apart when I tried to remove it from the three wheeler so I had to make a “new” setup. I bought the cheapest muffler I could find on eBay ($15 moped muffler) and some spare steel tubing I had and I welded up a temporary exhaust. I reused the old exhaust flange that mounts to the engine but I would like to replace all of it with new material when I finally transplant this engine in the go cart.
I then mounted the fuel tank I bought on ebay for $6. Fairly tiny with only 1L of capacity but the tank was pretty cheap and doesn’t leak… can’t complain about that.
I made the fuel tank mount out of some old aluminum sign material I had forever. I think I have been holding onto that material for over a decade now! Knew it would be useful some day :)
The fuel tank mount is designed to be unscrewed giving me more access to the engine when I start disassembly.
And it fired right up after filling the tank up. Glad I got the wiring right!
What is next is to disassembly and clean the entire engine. Once it heats up it smokes pretty good so I will need to at the minimal replace the piston rings and lap the valves. Probably end up honing the cylinder walls for the new rings.
At MacroFab we have a large industrial air compressor that provides compressed air to our pick and place and various machines. I want to monitor the compressors pressure and run time to help influence the maintenance schedule for it.
Those that listen to my podcast know that I enjoy working turning wrenches on vehicles and engines. Before my friend Stephen moved to Colorado he dropped off his old Honda ATC110 3 wheeler. It was in pretty bad shape. The drive train was all twisted up from when the chain fell off and jammed up. Fenders where cracked and the front fork was tweaked a bit. Only good thing was the 110cc engine fired up right away.
This gave me an idea. When I was younger I always wanted to build a go cart but never had the funds, tools, and my parents where very wary of the idea. Now I have a perfectly good 110cc engine, a welder, and no longer under the supervision of my parents :) .
After a couple 11mm and 14mm bolts the engine was freed from the old 3 wheeler chassis. Time to get rid of the old chassis and parts I am not going to use.
I looked online and these chassis’ don’t really sell and would be a pain to get rid of otherwise. A sawzall and cut off wheels made quick work of the pressed steel chassis and tubes.
With some scrap material I had left over from other projects, I fabricated an engine stand for the 110cc engine.
I then wired up the various electrical bits of the engine. These engines have very little electronics to drive them. An alternator generates the power for the sparkplug which is controlled by the CDI (Capacitor Discharge Ignition unit). I found the wiring diagram for this engine here.
On the other side of the engine stand I mounted the throttle and ignition coil.
What is left on the engine stand to build is an exhaust system and adding a fuel tank. For the exhaust I found a $15 mini bike/moped muffler and some 1″ 16AWG steel tubing. The fuel tank is a $6 plastic mini bike tank. Next update on this project I hope to have those installed and the engine running on the stand. This engine needs a complete tear down as it leaks from every seal and I would rather not get my new go cart all oily!
This is something I recorded with Stephen Kraig (Co-host of the MacroFab Engineering Podcast) back in September 2016. We never made it public till now! Drunken Gaming Night! It is silly and I have no idea where Stephen and I will take the channel but it is fun to do.
The DMG-01 Gameboy runs off all 5V logic and the FPGA I will be using (Cyclone 4 Altera) runs off 3.3V I/O. Conversion is needed to prevent frying the FPGA. I have used the TI part SN74LVC8T245 in the past with other FPGA projects and on the proof of concept VGA mod with the DE0 dev board.
The SN74LVC8T245’s output enable is active low so I pulled it high with a 10K resistor. This way the convertor is disabled till the FPGA can control the IC. Direction is set by default to be 5V -> 3.3V conversion with a 10K pull down.
I am also going to pull in the state of the buttons on the Gameboy. I hope to be able to have different modes that the FPGA can perform. Resolution changes and the like. Eventually I will design it so that FPGA can also drive the screen but that will probably be a future hardware revision.
Instead of trying to have an excuse of why I have not been posting here. Well go check out MacroFab. It is the company I co-founded a bit over 4 years ago now. I also am the co-host of the MEP or MacroFab Engineering Podcast. It is a weekly electronics podcast and we are currently on episode 119…and we have not missed a single week!
I have been doing side projects for fun but I have just been very bad about posting them here. Typically they just go to my twitter account and I talk about them on the podcast. I will be putting more effort into posting here.
With that out of the way… Current plan is to just look at my past incomplete projects and either finish them or kill them off. Starting with the FPGA Gameboy project. First order of business is to start making some dedicated hardware for the Gameboy. To quicken the development process I am going to lift the FPGA design block from the ChromaColor project. The FPGA is an older Cyclone 4 module (EP4CE6E22C8N) but it should do the trick and is still fairly affordable. I would like to move it to a newer platform like a 10M08SCU169C8G.
